Workshop services - Custom design and manufacturing

The MDL Énergie inc. workshop can provide custom design and manufacturing of various electrical equipment.

  • Design and manufacturing of connection boxes.
  • Medium and low voltage breakers upgrading.
  • Control and/or protection panels and cabinets design and manufacturing.
  • Digital measurement systems.
  • Isolated busduct repair and upgrading.
  • Connectors design and manufacturing.
